Digital LED Ammeter
Product Code : SCL-EAE-11352
This digital LED ammeter is intended for current-measurement activities in school, college, university and vocational laboratory circuits. Its LED readout allows the measured value to be viewed directly without interpreting the pointer and scale used on a conventional analogue meter.
The instrument can support practical lessons involving current flow, resistance, series circuits and parallel circuits when used within its specified electrical limits. The current range, resolution, accuracy class, enclosure material and terminal configuration must be ed against the supplied model before procurement or publication.
Key Features
Direct digital display: The LED display presents the current reading as a numerical value for straightforward observation.
Educational application: Suitable for supervised physics and basic electrical laboratory exercises.
Clear classroom visibility: The illuminated display helps instructors and students read measurements during demonstrations.
Series-circuit measurement: Designed to be connected in series with the load when measuring circuit current.
Practical learning support: Helps students compare current under different circuit conditions.
Laboratory format: Enclosure construction, terminals and mounting arrangement are available as [confirm].
Defined measurement limits: Current range, resolution and accuracy are supplied according to the ed model specification.
Technical Specifications
|
Specification |
Detail |
|
Product name |
Digital LED Ammeter |
|
Instrument type |
Digital electrical current meter |
|
Display |
LED digital display |
What's Included in the Kit
One Digital LED Ammeter
Connection leads or accessories.
Operating instructions or technical documentation.
Calibration or test certificate .
Applications / Uses
Measuring current in compatible educational circuits.
Demonstrating how an ammeter is connected in series.
Studying current in series and parallel circuit arrangements.
Supporting Ohm’s law experiments with suitable external apparatus.
Comparing current before and after changing resistance or load conditions.
Teaching basic electrical measurement in physics and vocational laboratories.
How to Use the Digital LED Ammeter
Check the instrument’s ed current type, range and terminal markings.
Switch off the circuit power before making connections.
Select the appropriate range where range selection is provided.
Connect the ammeter in series with the circuit load. Do not connect it directly across a power source.
Verify polarity when measuring direct current.
Energize the circuit and read the current value on the LED display.
Switch off the circuit before removing or changing any leads.
Safety note: Use the meter only within its ed voltage and current ratings. Laboratory work should be supervised by a qualified instructor. Never use damaged leads or exposed conductors.
Care & Maintenance
Disconnect the instrument before cleaning or storage.
Wipe the enclosure with a clean, dry cloth. Do not allow liquid to enter the display or terminals.
Store the meter in a dry location away from dust, moisture and excessive heat.
Inspect the terminals and connecting leads before each practical session.
Why Choose Lab Exports
Lab Exports is an Indian manufacturer, supplier and exporter of scientific and educational laboratory equipment. Established in 1986, the company supplies laboratory instruments, experiment setups and teaching equipment to schools, colleges, universities and other institutions. Its catalogue includes dedicated physics laboratory equipment and electrical and electronics laboratory equipment. Institutional buyers can also discuss bulk, tender and OEM requirements through the OEM and tenders service.
Frequently Asked Questions
What is a digital LED ammeter used for?
A digital LED ammeter is used to measure and display the electrical current flowing through a compatible circuit. It is connected in series with the circuit being tested.
Is this digital ammeter suitable for school laboratories?
It is intended for supervised educational experiments in physics and basic electrical laboratories. The selected model’s range should match the circuits used in the curriculum.
Does the instrument measure AC or DC current?
The applicable current type is [confirm]. Buyers should verify whether the quoted model measures AC, DC or both before ordering.
What is the measurement range of the ammeter?
The current range is [confirm]. The exact range, resolution and accuracy should appear on the quotation and product documentation.
How is an ammeter connected in a circuit?
An ammeter is connected in series so that the circuit current passes through the instrument. It must not be connected directly in parallel across a power supply.
Can calibration documentation be supplied?
Calibration or test documentation has not been verified for this model. Buyers should request the required certificate and calibration traceability when seeking a quotation.
Contact Lab Exports for ed specifications, institutional quantities and a quotation, or explore the complete electrical and electronics laboratory equipment range.
```
