MR66 Analog Panel Meter Manufacturer,Supplier and Exporter in India
Product Code : SCL-LM-11290
The MR66 Analog Panel Meter uses a pointer and graduated dial to provide a continuous visual indication of the connected electrical quantity. Unlike a digital display, an analog meter makes gradual changes, fluctuations and the direction of pointer movement easy to observe during practical demonstrations.
The instrument is designed for integration into a compatible laboratory panel, electrical trainer or demonstration board. Its measuring function, AC or DC configuration, electrical range, scale marking and terminal arrangement must match the intended circuit. These parameters should be confirmed before ordering or preparing the panel cut-out.
Key Features
Clear analog indication: A pointer and graduated scale provide direct visual measurement.
Continuous response: Pointer movement helps users observe gradual changes and fluctuations in a circuit.
Panel-mounted format: The meter can be integrated into compatible laboratory trainers and demonstration panels.
Educational functionality: It supports instruction in scale reading, pointer deflection and electrical measurement.
Selectable configuration: The required current or voltage range can be specified subject to confirmation and availability.
Simple operation: The analog display does not require menu navigation or display programming.
Practical visibility: The dial can be observed during individual experiments and teacher-led demonstrations.
Technical Specifications
|
Specification |
Detail |
|
Product name |
MR66 Analog Panel Meter |
|
Brand |
Lab Exports |
|
Instrument type |
Analog panel-mounted electrical indicating meter |
|
Display |
Pointer with graduated scale |
Applications and Uses
Displaying voltage or current in a compatible educational circuit
Installing in school and college physics-laboratory panels
Demonstrating analog pointer deflection
Teaching scale divisions, range selection and reading technique
Observing changes in electrical quantities during experiments
Integrating into vocational and technical electrical trainers
Supporting circuit-measurement demonstrations in STEM laboratories
How to Use the MR66 Analog Panel Meter
Check whether the meter is designed for current or voltage measurement.
Confirm its measuring range and AC or DC rating.
Inspect the pointer, scale window, terminals and enclosure.
Switch off the circuit supply before making connections.
Mount the meter securely in a compatible panel opening.
Connect an ammeter configuration in series with the circuit.
Connect a voltmeter configuration in parallel across the relevant component or supply.
Observe the specified polarity when using a polarity-sensitive DC meter.
Energise the circuit and read the pointer directly from the front at eye level.
Switch off the supply before changing or removing connections.
Safety note: Never apply an unknown or above-range input to the meter. Incorrect wiring, polarity or overloading may damage the internal movement. Students should use the instrument under qualified supervision.
Care & Maintenance
Clean the scale window with a soft, dry and non-abrasive cloth.
Keep the meter away from moisture, excessive dust, shock and strong magnetic fields.
Do not press, bend or manually reposition the pointer.
Check the zero position, terminals and mounting security before practical sessions.
Why Choose Lab Exports?
Lab Exports manufactures and exports scientific laboratory instruments, experiment setups, science kits, mathematics kits, didactic models and STEM equipment. Its product range serves schools, colleges, universities, vocational institutes and laboratory procurement projects. Electrical configuration details can be reviewed against the buyer’s intended application before supply. Buyers should specify the required function, range and AC or DC configuration when requesting a quotation.
Frequently Asked Questions
What is the MR66 Analog Panel Meter used for?
It is used to display a specified electrical quantity on a pointer-based scale in laboratory panels, teaching circuits and electrical training equipment.
Does the MR66 Analog Panel Meter measure current or voltage?
The required measuring function has not been specified. Buyers should confirm whether they need a current meter or voltage meter and provide the required measuring range.
Is the MR66 meter suitable for AC and DC circuits?
The AC or DC configuration depends on the selected version. Do not connect the meter until its electrical rating has been confirmed.
Can the MR66 Analog Panel Meter be used in schools?
Yes. It can support supervised physics and electrical laboratory activities involving circuit measurement, pointer deflection and analog scale reading.
How should an analog panel meter be connected?
An ammeter is normally connected in series, while a voltmeter is normally connected in parallel. The printed terminal markings and product-specific instructions take priority.
How can users avoid parallax error?
Read the pointer directly from the front at eye level. Viewing the scale from an angle can produce an incorrect reading.
Product Image ALT Text
MR66 Analog Panel Meter by Lab Exports with pointer display
Analog electrical panel meter for physics laboratory trainer
Pointer-type laboratory meter with graduated electrical scale
Panel-mounted analog meter for classroom circuit demonstrations
Specify the required measuring function and electrical range when requesting the MR66 meter, and explore the complete physics laboratory equipment range and laboratory instruments collection from Lab Exports.
