Analog Voltmeter Panel Type Manufacturer,Supplier and Exporter in India
Product Code : SCL-LM-11152
The Analog Ammeter Panel helps students observe and measure electric current during practical circuit experiments. Unlike a digital display, an analog meter uses a moving pointer and graduated scale, allowing learners to see changes in current visually as circuit conditions vary.
This instrument belongs to the broader Lab Meters range offered by Lab Exports. The exact measurement range, current type, scale divisions, accuracy, terminal arrangement and dimensions should be confirmed from the final product specification before publication or procurement.
Key Features
Visual analog indication: Uses a pointer and graduated scale to display electrical current.
Supports practical learning: Helps students relate circuit changes to observable movement of the meter pointer.
Suitable for laboratory panels: Intended for integration into compatible educational or experimental setups.
Useful for current-measurement experiments: Supports lessons involving electrical circuits and basic measurement principles.
Classroom-friendly demonstration: Suitable for supervised physics and electrical laboratory activities.
Complements related meters: Can be used alongside educational Panel Meters for broader electrical measurement studies.
Technical Specifications
|
Specification |
Detail |
|
Product Name |
Analog Ammeter Panel |
|
Brand |
Lab Exports |
|
Product Category |
Physics Lab – Lab Meters |
|
Measurement Function |
Electrical current indication |
|
Display Type |
Analog pointer and graduated scale |
What's Included in the Kit
1 × Analog Ammeter Panel
Any additional leads, mounting hardware, circuit accessories or supporting components should be confirmed from the final quotation or technical datasheet.
Applications / Uses
Measuring or indicating current in compatible educational circuits.
Demonstrating the correct use of an ammeter in a series circuit.
Supporting experiments on current, voltage and resistance relationships.
Comparing current under changing circuit conditions.
Using alongside a Voltmeter for electrical measurement lessons.
Supporting demonstrations with an Ohms Law Apparatus.
How to Use the Analog Ammeter Panel
Confirm the meter's specified current range and whether it is intended for AC or DC measurement.
Switch off the power supply before changing circuit connections.
Connect the ammeter in series with the circuit section where current is to be measured.
Observe correct terminal polarity when using a DC ammeter.
Apply power and read the pointer position against the graduated scale.
Switch off the circuit before disconnecting or changing the setup.
Safety note: Never exceed the specified measurement range. Do not connect an ammeter directly in parallel across a voltage source, as this can cause excessive current and damage the instrument or circuit.
Care & Maintenance
Keep the scale window clean using a soft, dry cloth.
Store the meter in a dry environment away from excessive moisture, dust and mechanical shock.
Do not overload the meter or force the pointer mechanism.
Inspect terminals and connections before laboratory use.
Why Choose Lab Exports?
Lab Exports manufactures, supplies and exports scientific laboratory instruments, educational experiment setups, science kits, mathematics kits, didactic models and STEM equipment. Its product portfolio supports schools, colleges, universities and other educational institutions.
The company's laboratory-meter range includes panel meters, ammeters, voltmeters, galvanometers and other instruments for physics experiments and classroom demonstrations. Product-specific ranges and configurations should always be verified against the final technical quotation before ordering.
Frequently Asked Questions
What is an Analog Ammeter Panel used for?
An Analog Ammeter Panel is used to indicate electrical current in a compatible circuit. It provides a pointer-based reading on a graduated scale.
How should an analog ammeter be connected in a circuit?
An ammeter is connected in series with the circuit branch whose current is being measured. The circuit should be switched off before connections are changed.
Can an Analog Ammeter Panel measure both AC and DC current?
That depends on the specific meter configuration. The supplied product data does not identify whether this model is designed for AC, DC or a particular current range, so this must be confirmed before ordering.
Is this ammeter suitable for school physics laboratories?
Yes. An analog ammeter can support supervised lessons on electric current, circuit measurement and basic electrical experiments in physics laboratories.
What is the measurement range of this Analog Ammeter Panel?
No verified measurement range was supplied. The required range should be confirmed from the product datasheet or quotation before publication and procurement.
What is the difference between an ammeter and a voltmeter?
An ammeter measures electric current and is connected in series with a circuit. A voltmeter measures potential difference and is generally connected in parallel across the component being measured.
Explore the complete Lab Meters collection from Lab Exports for related ammeters, voltmeters, galvanometers and educational electrical measuring instruments.
