Two Stroke Diesel Engine Manufacturer,Supplier and Exporter in India
Product Code : SCL-H-11192
The Two Stroke Diesel Engine didactic model simplifies intricate internal combustion principles for engineering student courses and vocational physics curriculum groups. Manufactured from a high-grade cast metal alloy and impact-resistant polymer composites, this cutaway model exhibits all internal mechanical interactions. It showcases how a compression-ignition engine achieves power strokes without standalone exhaust valves or complex intake camshaft linkages, relying instead on strategically placed cylinder ports.
This durable educational system is hand-cranked to safely actuate the crankshaft, moving the precision piston assembly up and down. A low-voltage integrated small light bulb system is included inside the cylinder head to simulate fuel injection and timing combustion sequences. Securely attached to a heavy-duty stable base, it offers clear mechanical visibility from any side of a shared classroom workbench.
Key Features
- Clear Sectional Cutaway: Exposes the inner cylinder structure, piston crown, and scavenge port paths for interactive viewing.
- Tactile Manual Operation: Driven via an attached hand crank wheel to safely demonstrate mechanical motion at controlled speeds.
- Synchronized Flash Simulation: Features a small, built-in light system to visually indicate the precise moment of fuel auto-ignition.
- Sturdy Structural Materials: Composed of durable cast aluminum alloy and reinforced polymers for standard institutional longevity.
- Pre-Assembled Design: Arrives mounted on a heavy, vibration-free support base to ensure safe classroom desk deployments.
Technical Specifications
<+
| Specification | Detail |
|---|---|
| Product Name | Two Stroke Diesel Engine Didactic Model |
| Brand | Lab Exports |
| Model Type | Sectional Cutaway Demonstrator |
| Chassis Material | Cast Metal Alloy and Rigid Industrial Polymers |
| Mounting Configuration | Integrated on a stable, wide-foot metal or wooden base [confirm base material] |
What's Included in the Kit
- One fully assembled Two Stroke Diesel Engine model with attached hand crank
- Integrated electrical ignition simulation light bulb module
- Heavy-duty desktop support platform base
- Basic instructional user guide outlining the thermodynamic stages
Applications / Uses
- Explaining the difference between port-controlled two-stroke cycles and valve-operated four-stroke designs in automotive workshops.
- Demonstrating fuel induction, rapid compression ignition, scavenging, and exhaust strokes during mechanical training.
- Serving as an interactive structural visual aid during fluid dynamics or basic thermodynamics presentations.
- Enhancing vocabulary comprehension of mechanical parts including connecting rods, wrist pins, and counterweighted crankshafts.
How to Use the Two Stroke Diesel Engine Didactic Model
Follow these steps to conduct an educational thermodynamic demonstration sequence:
- Place the engine demonstrator unit firmly on a level classroom table or science laboratory desk.
- Connect a low-voltage electrical wire source to the model terminals to activate the internal ignition light indicator system.
- Slowly turn the rear handle wheel in a clockwise motion to initiate movement in the internal connecting arm assembly.
- Observe the piston move downward, uncovering the transfer port to visualize how fresh air charges enter the cylinder.
- Rotate the wheel further to watch the piston rise, covering the ports to compress air before the simulation bulb illuminates at Top Dead Center (TDC).
Safety Note: Keep fingers clear of the exposed crank wheels and linking hinges during rapid manual rotations. Do not connect this model to high-voltage mains electricity outlets.
Care & Maintenance
- Apply a few drops of light machine oil to the exposed mechanical pivot hinges once per semester to prevent rust or binding.
- Wipe off airborne dust particles from the clear plastic parts using a clean, soft microfiber cloth to prevent surface scratching.
- Store the model away from damp chemical storage areas to protect the cast metal surfaces from environmental oxidation.
Why Choose Lab Exports
Lab Exports is an established global manufacturer and exporter of accurate scientific laboratory instruments, reliable lab experiment setups, and innovative student educational packages. Our manufacturing plants construct each model to strict quality controls to give classrooms dependable operational life over repeated semesters. Through advanced delivery workflows, we seamlessly transport precision didactic units and heavy training instruments to schools and global supply partners across the world.
Frequently Asked Questions
What is a Two Stroke Diesel Engine model used for?
It is used as a visual didactic tool to teach students how two-stroke compression-ignition engines operate without standard valve sub-systems.
Does it require actual diesel fuel to operate?
No, this is a non-functional educational model designed for manual hand-crank demonstrations; it uses a small light bulb rather than real combustion.
Is this model suitable for university-level engineering courses?
Yes, it serves as an excellent resource for explaining mechanical linkages, basic port geometry, and scavenging dynamics to technical students.
Can it be safely used in high schools?
Yes, because it is hand-operated and lacks real fuel or extreme heat, it is completely safe for junior high and high school physics classes.
What power source is needed for the combustion simulation light?
The internal simulation bulb requires a low-voltage DC power supply or simple bench batteries connected via the standard terminals [confirm exact specs].
