Analog Ammeter Panel Manufacturer,Supplier and Exporter in India
Product Code : SCL-LM-11151
The Analog Ammeter Panel Type provides a visual indication of electrical current through the movement of a pointer across a graduated dial. In educational experiments, an ammeter is connected in series with the circuit so that the current being studied passes through the measuring instrument.
This panel-type meter supports demonstrations of electric current, circuit behaviour, series connections, and introductory electrical measurements. It complements other laboratory meters for physics experiments, including voltmeters, galvanometers, multimeters, and related measuring instruments.
Key Features
Direct analog indication: Displays electrical current through pointer movement across a graduated scale.
Panel-type configuration: Intended for integration into compatible educational panels, demonstrators, or laboratory setups.
Supports current measurement: Helps students understand how electrical current is observed in a series-connected circuit.
Clear visual demonstration: Pointer displacement provides an immediate visual response to changes in current.
Suitable for practical instruction: Useful for teacher demonstrations, student experiments, and introductory circuit studies.
Relevant to STEM education: Supports hands-on learning of electricity, instrumentation, and electrical measurement principles.
Broad laboratory application: Suitable for compatible school, college, university, and technical-training laboratory setups.
Technical Specifications
|
Specification |
Detail |
|
Product Name |
Analog Ammeter Panel Type |
|
Brand |
Lab Exports |
|
Product Category |
Physics Laboratory Equipment / Lab Meters |
|
Instrument Type |
Panel-type analog ammeter |
|
Measured Quantity |
Electrical current |
|
Display Type |
Analog pointer with graduated scale |
What's Included in the Kit
1 x Analog Ammeter Panel Type instrument
Mounting hardware, leads, connectors, external shunts, protective components, and other accessories are not confirmed in the supplied product data and should be verified before procurement.
Applications / Uses
Demonstrating measurement of electrical current in basic circuits.
Teaching correct series connection of an ammeter.
Observing current changes when circuit conditions are varied.
Supporting school and college electricity experiments.
Integrating into compatible educational demonstration panels.
Complementing other electrical and electronics laboratory equipment used for circuit and instrumentation studies.
How to Use the Analog Ammeter Panel Type
Confirm the instrument's measurement range and electrical configuration before connecting it.
Switch off the experimental circuit before making or changing connections.
Connect the ammeter in series with the part of the circuit where current is to be measured.
Use the correct terminals and polarity where applicable to the specific meter design.
Energize the circuit and observe the pointer position on the graduated scale.
Read the current value according to the marked scale and selected range.
Switch off the circuit before disconnecting or changing the experimental setup.
Safety note: Never connect an ammeter directly across a voltage source as though it were a voltmeter. Confirm the correct range and circuit configuration before energizing the setup, and never exceed the instrument's rated measurement range.
Care & Maintenance
Keep the meter face clean and protect the transparent viewing surface from scratches.
Store or install the instrument in a dry location away from excessive moisture and impact.
Avoid mechanical shock that could affect the pointer mechanism.
Verify meter performance according to the laboratory's applicable inspection or calibration procedure when measurement reliability is important.
Why Choose Lab Exports
Lab Exports manufactures and exports scientific laboratory instruments, educational experiment setups, science kits, mathematics kits, didactic models, and STEM equipment. Its physics range covers laboratory meters, electrical and electronics apparatus, mechanics, optics, heat, magnetism, and other practical teaching equipment. Buyers can explore the wider physics laboratory equipment range for institutional and educational requirements. Exact range, electrical configuration, mounting dimensions, and tender-specific requirements should always be confirmed before ordering.
Frequently Asked Questions
What is an Analog Ammeter Panel Type used for?
An Analog Ammeter Panel Type is used to measure and visually indicate electrical current through pointer movement across a graduated scale. It is commonly used in compatible educational panels and laboratory circuit demonstrations.
How should an analog ammeter be connected in a circuit?
An ammeter is connected in series with the circuit branch in which current is to be measured. The exact terminals and polarity requirements depend on the specific meter configuration.
Is this Analog Ammeter suitable for school physics laboratories?
Yes. It is suitable for supervised demonstrations and practical activities involving current measurement, electrical circuits, and basic instrumentation in educational laboratories.
What is the measurement range of this ammeter?
The measurement range has not been specified in the supplied product data. Buyers should confirm the required current range before ordering.
Is this an AC or DC ammeter?
The supplied product information does not specify whether this model is designed for AC, DC, or a particular circuit configuration. That requirement should be confirmed before procurement.
What should buyers verify before ordering a panel ammeter?
Buyers should confirm the current range, AC or DC configuration, accuracy class, scale markings, panel dimensions, mounting cut-out, terminal arrangement, and any tender-specific requirements.
Explore the complete range of laboratory equipment for educational and scientific applications available from Lab Exports.
Recommended Product Image ALT Text: Analog Ammeter Panel Type for physics laboratory electrical current measurement experiments
